Smooth Sound
Factory Fit
REVOLUTION 3S3 OEM SERIES
Smooth, balanced sound from a true 3-way speaker system. The Revolution 3S3 OEM combines fabric dome tweeters with rigid aluminum construction for refined, musical performance across the entire frequency range-designed to fit directly into factory speaker locations.
Revolution 3 Musicality
True 3-Way Design
Drop-In OEM Fitment
For more information, please hover over the dot.
1
1. Concave paper dust cap for smooth sound and dispersion control
2
2. Paper membrane for smooth sound
3
3. Steel chassis for strength to minimize distortion
4
4. Paper membrane for smooth sound
5
5. Aluminum chassis for optimum strength to minimize distortion
6
6. 28mm (1.1 inch) fabric dome for detailed and smooth sound
7
7. Integrated aluminum housing to minimize distortion
1. Concave paper dust cap for smooth sound and dispersion control
2. Paper membrane for smooth sound
3. Steel chassis for strength to minimize distortion
4. Paper membrane for smooth sound
5. Aluminum chassis for optimum strength to minimize distortion
6. 28mm (1.1 inch) fabric dome for detailed and smooth sound
7. Integrated aluminum housing to minimize distortion
SPECIFICATION
Product Name
Crescendo Revolution 3S3 OEM
Product Type
3 way Speaker System
Midbass
Weight
Outside Diameter
Chasis
Moving Diameter
Membrane
Dust Cap
Motor System
Nominal Impedance
Nominal Power
Frequency Response (+/- 3dB)
884 gram
165 mm
Steel
132 mm
Paper
Concave Paper
Overhung with Ferrite Magnet
4 Ω
50 - 75 Watt RMS
60 Hz - 6 kHz
Midrange
Weight
Outside Diameter
Chasis
Moving Diameter
Membrane
Dust Cap
Motor System
Nominal Impedance
Nominal Power
Frequency Response (+/- 3dB)
391 gram
100 mm
Aluminum
61 mm
Paper
Concave Paper
Overhung with Ferrite Magnet
4 Ω
50 - 75 Watt RMS
250 Hz - 8 kHz
Tweeter
Weight
Outside Diameter
Housing
Moving Diameter
Membrane
Motor System
Nominal Impedance
Nominal Power
Frequency Response (+/- 3dB)
99 gram
57.5 mm
Integrated Aluminum
28 mm
Fabric Dome
Neodymium Magnet
4 Ω
50 - 75 Watt RMS
2 kHz - 20 kHz
REVOLUTION OEM SERIES
