Reference Grade
High Resolution
REVOLUTION 7 SPEAKER SERIES
Advanced composite cone technology delivers extended frequency response, precise imaging, and three-dimensional soundstage that reveals every layer in your music.
State-of-The-Art
Composites
Lifelike Listening
Experience
Ultimate Sound
Reproduction
For more information, please hover over the dot.
1
1. A.I designed a strong motor system
2
2. Treated paper dust cap with an integrated membrane
3
3. Custom designed grill for optimized sound clarity
4
4. Rigid aluminum chassis
5
5. Treated paper dust cap with an integrated membrane
6
6. Integrated aluminum grill
7
7. Rigid aluminum chassis
8
8. Strong Neodymium magnet
9
9. 40 mm fabric dome
10
10. Threaded stainless steel housing to strongly hold the tweeter
1. A.I designed a strong motor system
2. Treated paper dust cap with an integrated membrane
3. Custom designed grill for optimized sound clarity
4. Rigid aluminum chassis
5. Treated paper dust cap with an integrated membrane
6. Integrated aluminum grill
7. Rigid aluminum chassis
8. Strong Neodymium magnet
9. 40 mm fabric dome
10. Threaded stainless steel housing to strongly hold the tweeter
SPECIFICATION
Product Name
Crescendo Revolution 7S3
Product Type
3 way Speaker System
Midbass
Weight
Outside Diameter
Chasis
Moving Diameter
Membrane
Dust Cap
Motor System
Nominal Impedance
Nominal Power
Frequency Response (+/- 3dB)
1625 gram (1895 gram with Front Ring)
165 mm
Cast Aluminum
134 mm
Treated Paper
Integrated with Membrane
Overhung with Strong Ferrite Magnet
4 Ω
50 - 100 Watt RMS
55 Hz - 4.5 kHz
Midrange
Weight
Outside Diameter
Chasis
Moving Diameter
Membrane
Dust Cap
Motor System
Nominal Impedance
Nominal Power
Frequency Response (+/- 3dB)
413 gram
100 mm
Cast Aluminum
61 mm
Treated Paper
Integrated with Membrane
Strong Neodymium Magnet
4 Ω
50 - 75 Watt RMS
160 Hz - 12 kHz
Tweeter
Weight
Outside Diameter
Housing
Moving Diameter
Membrane
Motor System
Nominal Impedance
Nominal Power
Frequency Response (+/- 3dB)
233 gram
60.9 mm
Stainless Steel
24 mm
Fabric Dome
Neodymium Magnet
4 Ω
50 - 100 Watt RMS
2 kHz - 20 kHz
REVOLUTION SPEAKER SERIES
